/* ecgApplet.java */
/* */
/* Copyright (C) 2003 Mauricio Villarroel */
/* (mauricio DOT vllarroel AT estudiantes DOT ucb DOT edu DOT bo) */
/* */
/* ecgApplet.java and all its components are free software; you can */
/* redistribute them and/or modify it under the terms of the */
/* GNU General Public License as published by the Free Software */
/* Foundation; either version 2 of the License, or (at your option) */
/* any later version. */
/* */
/* This file is distributed in the hope that it will be useful, but */
/* WITHOUT ANY WARRANTY; without even the implied warranty of */
/* MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. */
/* See the GNU General Public License for more details. */
/* */
/************************************************************************/
/* */
/* This file was created for the ECGSYN Application. */
/* */
/* ECGSYN: A program for generating a realistic synthetic */
/* Electrocardiogram Signals. */
/* Copyright (c) 2003 by Patrick McSharry & Gari Clifford. */
/* All rights reserved. */
/* */
/* See IEEE Transactions On Biomedical Engineering, */
/* 50(3), 289-294, March 2003. */
/* Contact: */
/* P. McSharry (patrick AT mcsharry DOT net) */
/* G. Clifford (gari AT mit DOT edu) */
/* */
/************************************************************************/
/* */
/* Further updates to this software will be published on: */
/* http://www.physionet.org/ */
/* */
/************************************************************************/
import javax.swing.*;
import javax.swing.table.*;
import java.awt.*;
import java.text.*;
import java.util.Vector;
import java.io.File;
import java.io.IOException;
import java.awt.event.*;
import java.lang.Math.*;
import java.util.Timer;
import java.util.TimerTask;
/*
* This class formats a number in decimal notation or in
* scientific notation.
*/
class FormatNumber{
final static DecimalFormat dec1 = new DecimalFormat("0.0");
final static DecimalFormat dec2 = new DecimalFormat("0.00");
final static DecimalFormat sci1 = new DecimalFormat("0.0E0");
final static DecimalFormat sci2 = new DecimalFormat("0.00E0");
/*
* Formats the 'number' parameter and returns it as a String.
* precision = number of decimal places in the output.
*/
public static String toString( double number,
double upLimit,
double loLimit,
int precision)
{
// If number less than decimalLimit, or equal to zero, use decimal style
if( number == 0.0 ||
(Math.abs(number) <= upLimit && Math.abs(number) > loLimit) )
{
switch (precision){
case 1 : return dec1.format(number);
case 2 : return dec2.format(number);
default: return dec1.format(number);
}
} else{
// Create the format for Scientific Notation with E
switch (precision){
case 1 : return sci1.format(number);
case 2 : return sci2.format(number);
default: return sci1.format(number);
}
}
}
}
/*
*
* Public main class
*/
public class ecgApplet extends javax.swing.JApplet implements AdjustmentListener{
/**************************************
* Colors for the Plotting Components *
**************************************/
protected Color ecgPlotColor = Color.BLUE;
protected Color frameLineColor = Color.BLACK;
protected Color frameInsideLineColor = Color.LIGHT_GRAY;
protected Color frameFillColor = Color.WHITE;
protected Color axesNumColor = Color.GRAY;
protected Color titleColor = Color.BLACK;
protected Color bgColor = Color.WHITE;
/*********************************************
* These constants used in drawText() method
* for placement of the text within a given
* rectangular area.
*********************************************/
final int CENTER = 0;
final int LEFT = 1;
final int RIGHT = 2;
/*******************
* Frame Dimensions.
*******************/
final int posFrameX =0;
final int posFrameY =1;
final int frameHeight =290;
final int frameAmplitude = frameHeight/2;
//Coordinates Origin
final int posOriginY = posFrameY + (frameHeight/2);
//X coordinates
final int horzScaleY = posFrameY + frameHeight;
final int horzScaleWidth = 100;
final int horzScaleHeight = 20;
final int fScaleNumSize = 9;
/****************************************************
* Limit below which scale values use decimal format,
* above which they use scientific format.
****************************************************/
double upLimit = 100.0;
double loLimit = 0.01;
/******************************
* Ploting variables
******************************/
boolean readyToPlot;
int plotScrollBarValue;
double plotZoom = 0.008;
double plotZoomInc = 2;
/* Flag Variable, show if data has been generated. */
private boolean ecgGenerated = false;
/****************************************************************
* GLOBAL ECG PARAMETERS:
****************************************************************/
private int N; /* Number of heart beats */
private double hrstd; /* Heart rate std */
private double hrmean; /* Heart rate mean */
private double lfhfratio; /* LF/HF ratio */
private int sfecg; /* ECG sampling frequency */
private int sf; /* Internal sampling frequency */
private double amplitude; /* Amplitude for the plot area */
private int seed; /* Seed */
private double Anoise; /* Amplitude of additive uniform noise*/
private int period;
/* Define frequency parameters for rr process
* flo and fhi correspond to the Mayer waves and respiratory rate respectively
*/
private double flo; /* Low frequency */
private double fhi; /* High frequency */
private double flostd; /* Low frequency std */
private double fhistd; /* High frequency std */
/* Order of extrema: [P Q R S T] */
private double[] theta = new double[6]; /* ti not in radians*/
private double[] a = new double[6];
private double[] b = new double[6];
/*******************************
* Variable for the Data table
*******************************/
private String[] peakStr = {"", "P", "Q", "R", "S", "T"};
/******************************************
* Variables to Animate ECG
******************************************/
//Animating in process?
private boolean ecgAnimateFlg =false;
Timer ecgAnimateTimer;
private long ecgAnimateInterval;
/* Total plotting Data Table Row */
private int ecgAnimateNumRows;
/* Current plotting Data Table Row */
private int ecgAnimateCurRow;
/* Plot Area Panel width */
private int ecgAnimatePanelWidth;
/* Starting X axis value to plot*/
private int ecgAnimateInitialZero;
/* For plotting */
Point ecgAnimateLastPoint = new java.awt.Point(0, 0);
/** Initializes the applet ecgApplet */
public void init() {
initComponents();
initWindow();
}
private void initWindow(){
/*********************
*Init the main Window
*Set maximize
*********************/
try{
ecgWindow.setMaximum(true);
} catch(java.beans.PropertyVetoException e){
txtStatus.append("Exception Error : " + e + "\n");
}
/*********************
*Init the data Table
*********************/
tableValuesModel = new DefaultTableModel( new Object [][] {},
new String [] {"Time", "Voltage", "Peak"}){
Class[] types = new Class [] {
java.lang.String.class, java.lang.String.class, java.lang.String.class
};
public Class getColumnClass(int columnIndex) {
return types [columnIndex];
}
};
tableValues.setModel(tableValuesModel);
/* Init the ecgFrame */
ecgFrame = new ecgPanel();
ecgFrame.setBackground(new java.awt.Color(255, 255, 255));
ecgPlotArea.setViewportView(ecgFrame);
/* Set the ScrollBar */
plotScrollBar.addAdjustmentListener(this);
/* Set the size of the Dialogs */
paramDialog.setBounds(80, 80, 570,500);
alert.setBounds(80, 80, 540,200);
helpDialog.setBounds(80, 80, 600,500);
/*************************
* Reset all Application
* to a init state.
*************************/
resetECG();
}
private void initComponents() {//GEN-BEGIN:initComponents
paramDialog = new javax.swing.JDialog();
paramDesktopPane = new javax.swing.JDesktopPane();
closeParamDialogButton = new javax.swing.JButton();
resetParamDialogButton = new javax.swing.JButton();
saveParamDialogButton = new javax.swing.JButton();
paramTabbedPane = new javax.swing.JTabbedPane();
generalInterfacePanel = new javax.swing.JPanel();
txtSf = new javax.swing.JTextField();
lblSf = new javax.swing.JLabel();
lblN = new javax.swing.JLabel();
txtN = new javax.swing.JTextField();
lblHrmean = new javax.swing.JLabel();
txtHrmean = new javax.swing.JTextField();
lblHrstd = new javax.swing.JLabel();
txtHrstd = new javax.swing.JTextField();
lblAmplitude = new javax.swing.JLabel();
txtAmplitude = new javax.swing.JTextField();
lblGeneralTitle = new javax.swing.JLabel();
lblAnoise = new javax.swing.JLabel();
txtAnoise = new javax.swing.JTextField();
lblSfecg = new javax.swing.JLabel();
txtSfecg = new javax.swing.JTextField();
lblSeed = new javax.swing.JLabel();
txtSeed = new javax.swing.JTextField();
spectralCharacteristicsPanel = new javax.swing.JPanel();
lblSpectralTitle = new javax.swing.JLabel();
lblLfhfratio = new javax.swing.JLabel();
txtLfhfratio = new javax.swing.JTextField();
lblFlo = new javax.swing.JLabel();
txtFlo = new javax.swing.JTextField();
lblFhi = new javax.swing.JLabel();
txtFhi = new javax.swing.JTextField();
lblFlostd = new javax.swing.JLabel();
lblFhistd = new javax.swing.JLabel();
txtFhistd = new javax.swing.JTextField();
txtFlostd = new javax.swing.JTextField();
extremaPanel = new javax.swing.JPanel();
lblMorphologyTitle = new javax.swing.JLabel();
tiScrollPane = new javax.swing.JScrollPane();
tiTable = new javax.swing.JTable();
aiScrollPane = new javax.swing.JScrollPane();
aiTable = new javax.swing.JTable();
biScrollPane = new javax.swing.JScrollPane();
biTable = new javax.swing.JTable();
ExtremaLabelScrollPane = new javax.swing.JScrollPane();
ExtremaLabelTable = new javax.swing.JTable();
paramHelpButton = new javax.swing.JButton();
alert = new javax.swing.JDialog();
alertDesktopPane = new javax.swing.JDesktopPane();
alertText = new javax.swing.JTextArea();
alertButton = new javax.swing.JButton();
alertTitle = new javax.swing.JLabel();
exportDialog = new javax.swing.JDialog();
helpDialog = new javax.swing.JDialog();
helpInternalFrame = new javax.swing.JInternalFrame();
helpScrollPane = new javax.swing.JScrollPane();
helpEditorPane = new javax.swing.JEditorPane();
ecgWindow = new javax.swing.JInternalFrame();
desktopPane = new javax.swing.JDesktopPane();
jLabel1 = new javax.swing.JLabel();
jLabel2 = new javax.swing.JLabel();
jLabel3 = new javax.swing.JLabel();
jLabel4 = new javax.swing.JLabel();
jLabel5 = new javax.swing.JLabel();
jLabel6 = new javax.swing.JLabel();
jLabel7 = new javax.swing.JLabel();
lblMaxAmplitude = new javax.swing.JLabel();
lblOrigin = new javax.swing.JLabel();
lblMinAmplitude = new javax.swing.JLabel();
lblXAxis = new javax.swing.JLabel();
TableScrollPane = new javax.swing.JScrollPane();
tableValues = new javax.swing.JTable();
exportButton = new javax.swing.JButton();
plotScrollBar = new javax.swing.JScrollBar();
statusScrollPane = new javax.swing.JScrollPane();
txtStatus = new javax.swing.JTextArea();
ecgPlotArea = new javax.swing.JScrollPane();
animateDesktopPane = new javax.swing.JDesktopPane();
stopAnimateButton = new javax.swing.JButton();
startAnimateButton = new javax.swing.JButton();
calculateDesktopPane = new javax.swing.JDesktopPane();
generateButton = new javax.swing.JButton();
clearButton = new javax.swing.JButton();
paramButton = new javax.swing.JButton();
zommDesktopPane = new javax.swing.JDesktopPane();
zoomInButton = new javax.swing.JButton();
zoomOutButton = new javax.swing.JButton();
paramDialog.setTitle("Set ECG Parameters...");
paramDialog.setName("paramDialog");
closeParamDialogButton.setText("Close");
closeParamDialogButton.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
closeParamDialogButtonActionPerformed(evt);
}
});
closeParamDialogButton.setBounds(416, 400, 140, 30);
paramDesktopPane.add(closeParamDialogButton, javax.swing.JLayeredPane.DEFAULT_LAYER);
resetParamDialogButton.setText("Reset Values");
resetParamDialogButton.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
resetParamDialogButtonActionPerformed(evt);
}
});
resetParamDialogButton.setBounds(160, 400, 140, 30);
paramDesktopPane.add(resetParamDialogButton, javax.swing.JLayeredPane.DEFAULT_LAYER);
saveParamDialogButton.setText("Save Values");
saveParamDialogButton.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
saveParamDialogButtonActionPerformed(evt);
}
});
saveParamDialogButton.setBounds(7, 400, 140, 30);
paramDesktopPane.add(saveParamDialogButton, javax.swing.JLayeredPane.DEFAULT_LAYER);
paramTabbedPane.setBorder(new javax.swing.border.BevelBorder(javax.swing.border.BevelBorder.RAISED));
paramTabbedPane.setTabLayoutPolicy(javax.swing.JTabbedPane.SCROLL_TAB_LAYOUT);
generalInterfacePanel.setLayout(null);
generalInterfacePanel.setName("generalInterface");
txtSf.setToolTipText("");
txtSf.setInputVerifier(new sfVerifier());
generalInterfacePanel.add(txtSf);
txtSf.setBounds(350, 110, 110, 20);
lblSf.setHorizontalAlignment(javax.swing.SwingConstants.RIGHT);
lblSf.setText("Internal Sampling frequency [Hz]");
generalInterfacePanel.add(lblSf);
lblSf.setBounds(10, 110, 320, 16);
lblN.setHorizontalAlignment(javax.swing.SwingConstants.RIGHT);
lblN.setText("Approximate number of heart beats");
generalInterfacePanel.add(lblN);
lblN.setBounds(10, 50, 320, 16);
txtN.setToolTipText("");
txtN.setInputVerifier(new integerVerifier());
generalInterfacePanel.add(txtN);
txtN.setBounds(350, 50, 110, 20);
lblHrmean.setHorizontalAlignment(javax.swing.SwingConstants.RIGHT);
lblHrmean.setText("Heart rate mean [bpm]");
generalInterfacePanel.add(lblHrmean);
lblHrmean.setBounds(10, 170, 320, 16);
txtHrmean.setToolTipText("");
txtHrmean.setInputVerifier(new doubleVerifier());
generalInterfacePanel.add(txtHrmean);
txtHrmean.setBounds(350, 170, 110, 20);
lblHrstd.setHorizontalAlignment(javax.swing.SwingConstants.RIGHT);
lblHrstd.setText("Heart rate standard deviation [bpm]");
generalInterfacePanel.add(lblHrstd);
lblHrstd.setBounds(10, 200, 320, 16);
txtHrstd.setToolTipText("");
txtHrstd.setInputVerifier(new doubleVerifier());
generalInterfacePanel.add(txtHrstd);
txtHrstd.setBounds(350, 200, 110, 20);
lblAmplitude.setHorizontalAlignment(javax.swing.SwingConstants.RIGHT);
lblAmplitude.setText("Plot area Amplitude");
generalInterfacePanel.add(lblAmplitude);
lblAmplitude.setBounds(10, 260, 320, 16);
txtAmplitude.setToolTipText("");
txtAmplitude.setInputVerifier(new doubleVerifier());
generalInterfacePanel.add(txtAmplitude);
txtAmplitude.setBounds(350, 260, 110, 20);
lblGeneralTitle.setHorizontalAlignment(javax.swing.SwingConstants.CENTER);
lblGeneralTitle.setText("General Interface Parameters...");
generalInterfacePanel.add(lblGeneralTitle);
lblGeneralTitle.setBounds(120, 10, 350, 20);
lblAnoise.setHorizontalAlignment(javax.swing.SwingConstants.RIGHT);
lblAnoise.setText("Amplitude of additive uniform noise [mV]");
lblAnoise.setToolTipText("");
generalInterfacePanel.add(lblAnoise);
lblAnoise.setBounds(10, 140, 320, 16);
txtAnoise.setToolTipText("");
txtAnoise.setInputVerifier(new doubleVerifier());
txtAnoise.setName("Anoise");
generalInterfacePanel.add(txtAnoise);
txtAnoise.setBounds(350, 140, 110, 20);
lblSfecg.setHorizontalAlignment(javax.swing.SwingConstants.RIGHT);
lblSfecg.setText("ECG Sampling Frequency [Hz]");
generalInterfacePanel.add(lblSfecg);
lblSfecg.setBounds(10, 80, 320, 16);
txtSfecg.setToolTipText("");
txtSfecg.setInputVerifier(new sfecgVerifier());
generalInterfacePanel.add(txtSfecg);
txtSfecg.setBounds(350, 80, 110, 20);
lblSeed.setHorizontalAlignment(javax.swing.SwingConstants.RIGHT);
lblSeed.setText("Seed");
generalInterfacePanel.add(lblSeed);
lblSeed.setBounds(10, 230, 320, 16);
txtSeed.setToolTipText("");
txtSeed.setInputVerifier(new integerVerifier());
generalInterfacePanel.add(txtSeed);
txtSeed.setBounds(350, 230, 110, 20);
paramTabbedPane.addTab("General Interface", generalInterfacePanel);
spectralCharacteristicsPanel.setLayout(null);
spectralCharacteristicsPanel.setName("spectralCharacteristics");
lblSpectralTitle.setHorizontalAlignment(javax.swing.SwingConstants.CENTER);
lblSpectralTitle.setText("Spectral Characteristics Parameters...");
spectralCharacteristicsPanel.add(lblSpectralTitle);
lblSpectralTitle.setBounds(120, 10, 350, 20);
lblLfhfratio.setHorizontalAlignment(javax.swing.SwingConstants.RIGHT);
lblLfhfratio.setText("LF/HF ratio");
spectralCharacteristicsPanel.add(lblLfhfratio);
lblLfhfratio.setBounds(10, 170, 320, 16);
txtLfhfratio.setToolTipText("Low Frequency / High Frequency ratio");
txtLfhfratio.setInputVerifier(new doubleVerifier());
spectralCharacteristicsPanel.add(txtLfhfratio);
txtLfhfratio.setBounds(350, 170, 110, 20);
lblFlo.setHorizontalAlignment(javax.swing.SwingConstants.RIGHT);
lblFlo.setText("Low frequency [Hz]");
spectralCharacteristicsPanel.add(lblFlo);
lblFlo.setBounds(10, 50, 320, 16);
txtFlo.setToolTipText("");
txtFlo.setInputVerifier(new doubleVerifier());
spectralCharacteristicsPanel.add(txtFlo);
txtFlo.setBounds(350, 50, 110, 20);
lblFhi.setHorizontalAlignment(javax.swing.SwingConstants.RIGHT);
lblFhi.setText("High frequency [Hz]");
spectralCharacteristicsPanel.add(lblFhi);
lblFhi.setBounds(10, 80, 320, 16);
txtFhi.setToolTipText("");
txtFhi.setInputVerifier(new doubleVerifier());
spectralCharacteristicsPanel.add(txtFhi);
txtFhi.setBounds(350, 80, 110, 20);
lblFlostd.setHorizontalAlignment(javax.swing.SwingConstants.RIGHT);
lblFlostd.setText("Low frequency standard deviation [Hz]");
spectralCharacteristicsPanel.add(lblFlostd);
lblFlostd.setBounds(10, 110, 320, 16);
lblFhistd.setHorizontalAlignment(javax.swing.SwingConstants.RIGHT);
lblFhistd.setText("High frequency standard deviation [Hz]");
lblFhistd.setToolTipText("");
spectralCharacteristicsPanel.add(lblFhistd);
lblFhistd.setBounds(10, 140, 320, 16);
txtFhistd.setToolTipText("");
txtFhistd.setInputVerifier(new doubleVerifier());
txtFhistd.setName("Anoise");
spectralCharacteristicsPanel.add(txtFhistd);
txtFhistd.setBounds(350, 140, 110, 20);
txtFlostd.setToolTipText("");
txtFlostd.setInputVerifier(new doubleVerifier());
spectralCharacteristicsPanel.add(txtFlostd);
txtFlostd.setBounds(350, 110, 110, 20);
paramTabbedPane.addTab("Spectral Characteristics", spectralCharacteristicsPanel);
extremaPanel.setLayout(null);
lblMorphologyTitle.setHorizontalAlignment(javax.swing.SwingConstants.CENTER);
lblMorphologyTitle.setText("Order of Extrema...");
extremaPanel.add(lblMorphologyTitle);
lblMorphologyTitle.setBounds(90, 10, 350, 20);
tiScrollPane.setBorder(new javax.swing.border.EmptyBorder(new java.awt.Insets(1, 1, 1, 1)));
tiScrollPane.setViewportBorder(new javax.swing.border.EmptyBorder(new java.awt.Insets(1, 1, 1, 1)));
tiTable.setModel(new javax.swing.table.DefaultTableModel(
new Object [][] {
{null},
{null},
{null},
{null},
{null}
},
new String [] {
"Theta"
}
) {
Class[] types = new Class [] {
java.lang.Double.class
};
public Class getColumnClass(int columnIndex) {
return types [columnIndex];
}
});
tiScrollPane.setViewportView(tiTable);
extremaPanel.add(tiScrollPane);
tiScrollPane.setBounds(170, 80, 80, 120);
aiScrollPane.setBorder(new javax.swing.border.EmptyBorder(new java.awt.Insets(1, 1, 1, 1)));
aiScrollPane.setViewportBorder(new javax.swing.border.EmptyBorder(new java.awt.Insets(1, 1, 1, 1)));
aiTable.setModel(new javax.swing.table.DefaultTableModel(
new Object [][] {
{null},
{null},
{null},
{null},
{null}
},
new String [] {
"a"
}
) {
Class[] types = new Class [] {
java.lang.Double.class
};
public Class getColumnClass(int columnIndex) {
return types [columnIndex];
}
});
aiScrollPane.setViewportView(aiTable);
extremaPanel.add(aiScrollPane);
aiScrollPane.setBounds(280, 80, 80, 120);
biScrollPane.setBorder(new javax.swing.border.EmptyBorder(new java.awt.Insets(1, 1, 1, 1)));
biScrollPane.setViewportBorder(new javax.swing.border.EmptyBorder(new java.awt.Insets(1, 1, 1, 1)));
biTable.setModel(new javax.swing.table.DefaultTableModel(
new Object [][] {
{null},
{null},
{null},
{null},
{null}
},
new String [] {
"b"
}
) {
Class[] types = new Class [] {
java.lang.Double.class
};
public Class getColumnClass(int columnIndex) {
return types [columnIndex];
}
});
biScrollPane.setViewportView(biTable);
extremaPanel.add(biScrollPane);
biScrollPane.setBounds(390, 80, 80, 120);
ExtremaLabelScrollPane.setBorder(new javax.swing.border.EmptyBorder(new java.awt.Insets(1, 1, 1, 1)));
ExtremaLabelScrollPane.setHorizontalScrollBarPolicy(javax.swing.JScrollPane.HORIZONTAL_SCROLLBAR_NEVER);
ExtremaLabelScrollPane.setVerticalScrollBarPolicy(javax.swing.JScrollPane.VERTICAL_SCROLLBAR_NEVER);
ExtremaLabelScrollPane.setViewportBorder(new javax.swing.border.EmptyBorder(new java.awt.Insets(1, 1, 1, 1)));
ExtremaLabelScrollPane.setEnabled(false);
ExtremaLabelTable.setBackground((java.awt.Color) javax.swing.UIManager.getDefaults().get("Button.background"));
ExtremaLabelTable.setFont(new java.awt.Font("Dialog", 1, 12));
ExtremaLabelTable.setModel(new javax.swing.table.DefaultTableModel(
new Object [][] {
{" P(1) :"},
{" Q(2) :"},
{" R(3) :"},
{" S(4) :"},
{" T(5) :"}
},
new String [] {
"peak label"
}
) {
Class[] types = new Class [] {
java.lang.String.class
};
boolean[] canEdit = new boolean [] {
false
};
public Class getColumnClass(int columnIndex) {
return types [columnIndex];
}
public boolean isCellEditable(int rowIndex, int columnIndex) {
return canEdit [columnIndex];
}
});
ExtremaLabelTable.setGridColor((java.awt.Color) javax.swing.UIManager.getDefaults().get("Button.background"));
ExtremaLabelTable.setEnabled(false);
ExtremaLabelScrollPane.setViewportView(ExtremaLabelTable);
extremaPanel.add(ExtremaLabelScrollPane);
ExtremaLabelScrollPane.setBounds(40, 80, 110, 120);
paramTabbedPane.addTab("ECG Morphology", extremaPanel);
paramTabbedPane.setBounds(7, 10, 550, 380);
paramDesktopPane.add(paramTabbedPane, javax.swing.JLayeredPane.DEFAULT_LAYER);
paramHelpButton.setText("Help");
paramHelpButton.setEnabled(false);
paramHelpButton.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
paramHelpButtonActionPerformed(evt);
}
});
paramHelpButton.setBounds(310, 400, 100, 30);
paramDesktopPane.add(paramHelpButton, javax.swing.JLayeredPane.DEFAULT_LAYER);
paramDialog.getContentPane().add(paramDesktopPane, java.awt.BorderLayout.CENTER);
alert.setModal(true);
alertText.setBackground((java.awt.Color) javax.swing.UIManager.getDefaults().get("Desktop.background"));
alertText.setEditable(false);
alertText.setLineWrap(true);
alertText.setRows(10);
alertText.setWrapStyleWord(true);
alertText.setBounds(10, 10, 520, 80);
alertDesktopPane.add(alertText, javax.swing.JLayeredPane.DEFAULT_LAYER);
alertButton.setText("OK");
alertButton.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
alertButtonActionPerformed(evt);
}
});
alertButton.setBounds(230, 110, 80, -1);
alertDesktopPane.add(alertButton, javax.swing.JLayeredPane.DEFAULT_LAYER);
alertTitle.setBounds(0, 0, 350, -1);
alertDesktopPane.add(alertTitle, javax.swing.JLayeredPane.DEFAULT_LAYER);
alert.getContentPane().add(alertDesktopPane, java.awt.BorderLayout.CENTER);
exportDialog.setModal(true);
helpInternalFrame.setTitle("ECG Help");
helpInternalFrame.setVisible(true);
helpEditorPane.setEditable(false);
helpScrollPane.setViewportView(helpEditorPane);
helpInternalFrame.getContentPane().add(helpScrollPane, java.awt.BorderLayout.CENTER);
helpDialog.getContentPane().add(helpInternalFrame, java.awt.BorderLayout.CENTER);
setFocusCycleRoot(false);
setName("ecgpanel");
ecgWindow.setBorder(new javax.swing.border.BevelBorder(javax.swing.border.BevelBorder.RAISED));
ecgWindow.setTitle("Electrocardiogram Signals (ECG)");
try {
ecgWindow.setSelected(true);
} catch (java.beans.PropertyVetoException e1) {
e1.printStackTrace();
}
ecgWindow.setVisible(true);
jLabel1.setHorizontalAlignment(javax.swing.SwingConstants.CENTER);
jLabel1.setText("V");
jLabel1.setBounds(0, 110, 20, 16);
desktopPane.add(jLabel1, javax.swing.JLayeredPane.DEFAULT_LAYER);
jLabel2.setHorizontalAlignment(javax.swing.SwingConstants.CENTER);
jLabel2.setText("o");
jLabel2.setBounds(0, 130, 20, 16);
desktopPane.add(jLabel2, javax.swing.JLayeredPane.DEFAULT_LAYER);
jLabel3.setHorizontalAlignment(javax.swing.SwingConstants.CENTER);
jLabel3.setText("l");
jLabel3.setBounds(0, 150, 20, 16);
desktopPane.add(jLabel3, javax.swing.JLayeredPane.DEFAULT_LAYER);
jLabel4.setHorizontalAlignment(javax.swing.SwingConstants.CENTER);
jLabel4.setText("t");
jLabel4.setBounds(0, 170, 20, 16);
desktopPane.add(jLabel4, javax.swing.JLayeredPane.DEFAULT_LAYER);
jLabel5.setHorizontalAlignment(javax.swing.SwingConstants.CENTER);
jLabel5.setText("a");
jLabel5.setBounds(0, 190, 20, 16);
desktopPane.add(jLabel5, javax.swing.JLayeredPane.DEFAULT_LAYER);
jLabel6.setHorizontalAlignment(javax.swing.SwingConstants.CENTER);
jLabel6.setText("g");
jLabel6.setBounds(0, 210, 20, 16);
desktopPane.add(jLabel6, javax.swing.JLayeredPane.DEFAULT_LAYER);
jLabel7.setHorizontalAlignment(javax.swing.SwingConstants.CENTER);
jLabel7.setText("e");
jLabel7.setBounds(0, 230, 20, 16);
desktopPane.add(jLabel7, javax.swing.JLayeredPane.DEFAULT_LAYER);
lblMaxAmplitude.setFont(new java.awt.Font("Dialog", 1, 9));
lblMaxAmplitude.setText("0.001");
lblMaxAmplitude.setBounds(30, 25, 40, 12);
desktopPane.add(lblMaxAmplitude, javax.swing.JLayeredPane.DEFAULT_LAYER);
lblOrigin.setFont(new java.awt.Font("Dialog", 1, 9));
lblOrigin.setText("0.00");
lblOrigin.setBounds(30, 167, 40, 12);
desktopPane.add(lblOrigin, javax.swing.JLayeredPane.DEFAULT_LAYER);
lblMinAmplitude.setFont(new java.awt.Font("Dialog", 1, 9));
lblMinAmplitude.setText("-0.001");
lblMinAmplitude.setBounds(30, 309, 40, 12);
desktopPane.add(lblMinAmplitude, javax.swing.JLayeredPane.DEFAULT_LAYER);
lblXAxis.setHorizontalAlignment(javax.swing.SwingConstants.CENTER);
lblXAxis.setText("Time");
lblXAxis.setBounds(73, 367, 580, 16);
desktopPane.add(lblXAxis, javax.swing.JLayeredPane.DEFAULT_LAYER);
TableScrollPane.setBorder(new javax.swing.border.TitledBorder(null, "Data Table", javax.swing.border.TitledBorder.CENTER, javax.swing.border.TitledBorder.ABOVE_TOP));
TableScrollPane.setHorizontalScrollBarPolicy(javax.swing.JScrollPane.HORIZONTAL_SCROLLBAR_ALWAYS);
TableScrollPane.setVerticalScrollBarPolicy(javax.swing.JScrollPane.VERTICAL_SCROLLBAR_ALWAYS);
tableValues.setAutoResizeMode(javax.swing.JTable.AUTO_RESIZE_OFF);
TableScrollPane.setViewportView(tableValues);
TableScrollPane.setBounds(658, 2, 250, 510);
desktopPane.add(TableScrollPane, javax.swing.JLayeredPane.DEFAULT_LAYER);
exportButton.setText("Export Table Data...");
exportButton.setEnabled(false);
exportButton.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
exportButtonActionPerformed(evt);
}
});
exportButton.setBounds(658, 515, 250, 20);
desktopPane.add(exportButton, javax.swing.JLayeredPane.DEFAULT_LAYER);
plotScrollBar.setMaximum(0);
plotScrollBar.setOrientation(javax.swing.JScrollBar.HORIZONTAL);
plotScrollBar.setName("timeScroll");
plotScrollBar.setBounds(73, 352, 580, 17);
desktopPane.add(plotScrollBar, javax.swing.JLayeredPane.DEFAULT_LAYER);
statusScrollPane.setBorder(new javax.swing.border.TitledBorder(new javax.swing.border.BevelBorder(javax.swing.border.BevelBorder.RAISED), "Status and Messages:", javax.swing.border.TitledBorder.LEFT, javax.swing.border.TitledBorder.ABOVE_TOP));
statusScrollPane.setVerticalScrollBarPolicy(javax.swing.JScrollPane.VERTICAL_SCROLLBAR_ALWAYS);
txtStatus.setEditable(false);
statusScrollPane.setViewportView(txtStatus);
statusScrollPane.setBounds(234, 385, 420, 150);
desktopPane.add(statusScrollPane, javax.swing.JLayeredPane.DEFAULT_LAYER);
ecgPlotArea.setBorder(new javax.swing.border.TitledBorder(new javax.swing.border.BevelBorder(javax.swing.border.BevelBorder.RAISED), "Plot Area", javax.swing.border.TitledBorder.CENTER, javax.swing.border.TitledBorder.ABOVE_TOP));
ecgPlotArea.setHorizontalScrollBarPolicy(javax.swing.JScrollPane.HORIZONTAL_SCROLLBAR_NEVER);
ecgPlotArea.setVerticalScrollBarPolicy(javax.swing.JScrollPane.VERTICAL_SCROLLBAR_NEVER);
ecgPlotArea.setBounds(73, 2, 580, 350);
desktopPane.add(ecgPlotArea, javax.swing.JLayeredPane.DEFAULT_LAYER);
animateDesktopPane.setBorder(new javax.swing.border.TitledBorder(new javax.swing.border.LineBorder(new java.awt.Color(0, 0, 0)), "Animate"));
stopAnimateButton.setFont(new java.awt.Font("Dialog", 1, 11));
stopAnimateButton.setText("Stop");
stopAnimateButton.setEnabled(false);
stopAnimateButton.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
stopAnimateButtonActionPerformed(evt);
}
});
stopAnimateButton.setBounds(120, 17, 90, 20);
animateDesktopPane.add(stopAnimateButton, javax.swing.JLayeredPane.DEFAULT_LAYER);
startAnimateButton.setFont(new java.awt.Font("Dialog", 1, 11));
startAnimateButton.setText("Start");
startAnimateButton.setEnabled(false);
startAnimateButton.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
startAnimateButtonActionPerformed(evt);
}
});
startAnimateButton.setBounds(7, 17, 90, 20);
animateDesktopPane.add(startAnimateButton, javax.swing.JLayeredPane.DEFAULT_LAYER);
animateDesktopPane.setBounds(7, 492, 220, 45);
desktopPane.add(animateDesktopPane, javax.swing.JLayeredPane.DEFAULT_LAYER);
calculateDesktopPane.setBorder(new javax.swing.border.TitledBorder(new javax.swing.border.LineBorder(new java.awt.Color(0, 0, 0)), "Calculate ECG"));
generateButton.setFont(new java.awt.Font("Dialog", 1, 11));
generateButton.setText("Generate");
generateButton.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
generateButtonActionPerformed(evt);
}
});
generateButton.setBounds(7, 17, 90, 20);
calculateDesktopPane.add(generateButton, javax.swing.JLayeredPane.DEFAULT_LAYER);
clearButton.setFont(new java.awt.Font("Dialog", 1, 11));
clearButton.setText("Clear");
clearButton.setEnabled(false);
clearButton.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
clearButtonActionPerformed(evt);
}
});
clearButton.setBounds(120, 17, 90, 20);
calculateDesktopPane.add(clearButton, javax.swing.JLayeredPane.DEFAULT_LAYER);
paramButton.setFont(new java.awt.Font("Dialog", 1, 11));
paramButton.setText("Set Parameters...");
paramButton.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
paramButtonActionPerformed(evt);
}
});
paramButton.setBounds(7, 42, 130, 20);
calculateDesktopPane.add(paramButton, javax.swing.JLayeredPane.DEFAULT_LAYER);
calculateDesktopPane.setBounds(7, 377, 220, 70);
desktopPane.add(calculateDesktopPane, javax.swing.JLayeredPane.DEFAULT_LAYER);
zommDesktopPane.setBorder(new javax.swing.border.TitledBorder(new javax.swing.border.LineBorder(new java.awt.Color(0, 0, 0)), "Zoom plot area"));
zoomInButton.setFont(new java.awt.Font("Dialog", 1, 14));
zoomInButton.setText("+");
zoomInButton.setEnabled(false);
zoomInButton.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
zoomInButtonActionPerformed(evt);
}
});
zoomInButton.setBounds(120, 17, 90, 20);
zommDesktopPane.add(zoomInButton, javax.swing.JLayeredPane.DEFAULT_LAYER);
zoomOutButton.setFont(new java.awt.Font("Dialog", 1, 14));
zoomOutButton.setText("-");
zoomOutButton.setEnabled(false);
zoomOutButton.addActionListener(new java.awt.event.ActionListener() {
public void actionPerformed(java.awt.event.ActionEvent evt) {
zoomOutButtonActionPerformed(evt);
}
});
zoomOutButton.setBounds(7, 17, 90, 20);
zommDesktopPane.add(zoomOutButton, javax.swing.JLayeredPane.DEFAULT_LAYER);
zommDesktopPane.setBounds(7, 447, 220, 45);
desktopPane.add(zommDesktopPane, javax.swing.JLayeredPane.DEFAULT_LAYER);
ecgWindow.getContentPane().add(desktopPane, java.awt.BorderLayout.CENTER);
getContentPane().add(ecgWindow, java.awt.BorderLayout.CENTER);
}//GEN-END:initComponents
private void paramHelpButtonActionPerformed(java.awt.event.ActionEvent evt) {//GEN-FIRST:event_paramHelpButtonActionPerformed
helpEditorPane.setContentType("text/html");
helpEditorPane.setText( "<html> <body>" +
"<font size='3'>"+
"<table width='400' border='0' align='center' cellpadding='0' cellspacing='5'>" +
" <tr> " +
" <td height='50' align='left' valign='middle'><strong><font color='#FF0000' size='4' face='Arial, Helvetica, sans-serif'>ECGSYN " +
" PARAMETER DOCUMENTATION</font></strong></td>" +
" </tr>" +
" <tr> " +
" <td height='30' align='left' valign='top'><strong><font color='#0000FF'>GENERAL " +
" INTERFACE</font></strong></td> "+
" </tr>" +
" <tr> " +
" <td align='left' valign='top'> <table width='100%' border='0' cellspacing='5' cellpadding='5'>" +
" <tr> " +
" <td width='60'> </td>" +
" <td><strong>Approximate number of heart beats:</strong><br>" +
" fjaklsdfjasldjasdjfgfagsdgfasdgfywerwaegsdgfwefasjkgiawegasfkgiawefaklsdgfaiwegfklasegfaiwegaklgawiegfafwgegfauiwegfkasdgfiawegfawiegfasdklgfialweugfasefiuawgefilugfawileugfawilegfaweilgfawilegfasiduflskdgfailwuegfawileusdjklgfawilesdfk</td>" +
" </tr>" +
" <tr>" +
" <td width='60'> </td>" +
" <td><strong><dt>ECG Sampling Frequency</dt></strong>" +
" <dd>definition</dd></td>" +
" </tr>" +
" <tr>" +
" <td width='60'> </td>" +
" <td><strong><dt>Internal Sampling Frequency</dt></strong>" +
" <dd>definition</dd></td>" +
" </tr>" +
" <tr>" +
" <td width='60'> </td>" +
" <td><strong><dt>Amplitude of additive uniform noise</dt></strong>" +
" <dd>definition</dd></td>" +
" </tr>" +
" <tr>" +
" <td width='60'> </td>" +
" <td><strong><dt>Heart rate mean</dt></strong>" +
" <dd>definition</dd></td>" +
" </tr>" +
" <tr>" +
" <td width='60'> </td>" +
" <td><strong><dt>Heart rate standard deviation</dt></strong>" +
" <dd>definition</dd></td>" +
" </tr>" +
" <tr>" +
" <td width='60'> </td>" +
" <td><strong><dt>Seed</dt></strong>" +
" <dd>definition</dd></td>" +
" </tr>" +
" </table></td>" +
" </tr>" +
"</table>" +
"</font>" +
"</body> </html>");
helpDialog.show();
}//GEN-LAST:event_paramHelpButtonActionPerformed
private void alertButtonActionPerformed(java.awt.event.ActionEvent evt) {//GEN-FIRST:event_alertButtonActionPerformed
alert.hide();
}//GEN-LAST:event_alertButtonActionPerformed
private void zoomInButtonActionPerformed(java.awt.event.ActionEvent evt) {//GEN-FIRST:event_zoomInButtonActionPerformed
desktopPane.setCursor(java.awt.Cursor.getPredefinedCursor(java.awt.Cursor.WAIT_CURSOR));
paramDialog.hide();
plotZoom = plotZoom / plotZoomInc;
ecgFrame.repaint();
desktopPane.setCursor(java.awt.Cursor.getPredefinedCursor(java.awt.Cursor.DEFAULT_CURSOR));
}//GEN-LAST:event_zoomInButtonActionPerformed
private void zoomOutButtonActionPerformed(java.awt.event.ActionEvent evt) {//GEN-FIRST:event_zoomOutButtonActionPerformed
desktopPane.setCursor(java.awt.Cursor.getPredefinedCursor(java.awt.Cursor.WAIT_CURSOR));
paramDialog.hide();
plotZoom = plotZoom * plotZoomInc;
ecgFrame.repaint();
desktopPane.setCursor(java.awt.Cursor.getPredefinedCursor(java.awt.Cursor.DEFAULT_CURSOR));
}//GEN-LAST:event_zoomOutButtonActionPerformed
private void startAnimateButtonActionPerformed(java.awt.event.ActionEvent evt) {//GEN-FIRST:event_startAnimateButtonActionPerformed
paramDialog.hide();
// Disabling automatic plot
readyToPlot = false;
ecgFrame.repaint();
/*
* Initialize ECG Animate variables
*/
ecgAnimateFlg = true;
ecgAnimateNumRows = tableValuesModel.getRowCount();
ecgAnimateCurRow = 0;
ecgAnimatePanelWidth = ecgFrame.getBounds().width;
ecgAnimateInitialZero = 0;
ecgAnimateLastPoint.setLocation(0, posOriginY - (int)(Double.valueOf(tableValues.getValueAt(0, 1).toString()).doubleValue() * frameAmplitude / amplitude));
/* Create Timer */
ecgAnimateTimer = new Timer();
/* Schedule the Animate Plotting Task */
ecgAnimateTimer.scheduleAtFixedRate(new ECGAnimate(), 0, ecgAnimateInterval);
/* Set the Animate Buttons */
startECGAnimationSetControls();
}//GEN-LAST:event_startAnimateButtonActionPerformed
private void saveParamDialogButtonActionPerformed(java.awt.event.ActionEvent evt) {//GEN-FIRST:event_saveParamDialogButtonActionPerformed
saveParametersValues();
paramDialog.hide();
}//GEN-LAST:event_saveParamDialogButtonActionPerformed
private void resetParamDialogButtonActionPerformed(java.awt.event.ActionEvent evt) {//GEN-FIRST:event_resetParamDialogButtonActionPerformed
clearParameters();
}//GEN-LAST:event_resetParamDialogButtonActionPerformed
private void closeParamDialogButtonActionPerformed(java.awt.event.ActionEvent evt) {//GEN-FIRST:event_closeParamDialogButtonActionPerformed
paramDialog.hide();
}//GEN-LAST:event_closeParamDialogButtonActionPerformed
private void paramButtonActionPerformed(java.awt.event.ActionEvent evt) {//GEN-FIRST:event_paramButtonActionPerformed
paramDialog.show();
}//GEN-LAST:event_paramButtonActionPerformed
private void exportButtonActionPerformed(java.awt.event.ActionEvent evt) {//GEN-FIRST:event_exportButtonActionPerformed
paramDialog.hide();
exportDialog.setBounds(80, 80,500,500);
exportDialog.show();
}//GEN-LAST:event_exportButtonActionPerformed
private void saveParametersValues(){
txtStatus.setText(null);
checkParameters();
}
private void clearDataTable(){
// Delete the DataTable
tableValuesModel.setRowCount(0);
}
/**
* Draw a string in the center of a given box.
* Reduce the font size if necessary to fit. Can
* fix the type size to a value passed as an argument.
* The position of the string within the box passed
* as LEFT, CENTER or RIGHT constant value.
* Don't draw the strings if they do not fit.
*/
private int drawText( Graphics g, String msg, int xBox, int yBox, int boxWidth, int boxHeight,
int fixedTypeSizeValue, int position){
boolean fixedTypeSize = false;
int typeSize = 24;
// Fixed to a particular type size.
if(fixedTypeSizeValue > 0) {
fixedTypeSize = true;
typeSize = fixedTypeSizeValue;
}
int typeSizeMin = 8;
int x=xBox,y=yBox;
do {
// Create the font and pass it to the Graphics context
g.setFont(new Font("Monospaced",Font.PLAIN,typeSize));
// Get measures needed to center the message
FontMetrics fm = g.getFontMetrics();
// How many pixels wide is the string
int msgWidth = fm.stringWidth(msg);
// How tall is the text?
int msgHeight = fm.getHeight();
// See if the text will fit in the allotted
// vertical limits
if( msgHeight < boxHeight && msgWidth < boxWidth) {
y = yBox + boxHeight/2 +(msgHeight/2);
if( position == CENTER)
x = xBox + boxWidth/2 - (msgWidth/2);
else if(position == RIGHT)
x = xBox + boxWidth - msgWidth;
else
x = xBox;
break;
}
// If fixedTypeSize and wouldn't fit, don't draw.
if( fixedTypeSize) return -1;
// Try smaller type
typeSize -= 2;
} while (typeSize >= typeSizeMin);
// Don't display the numbers if they did not fit
if( typeSize < typeSizeMin) return -1;
// Otherwise, draw and return positive signal.
g.drawString(msg,x,y);
// ecgFrame.revalidate();
// ecgFrame.repaint();
return typeSize;
}
/*
* ReInit the Button Parameters' values
*/
private void clearParameters(){
/* General Intergace parameters */
txtN.setText("256");
N = 256;
txtSfecg.setText("256");
sfecg = 256;
txtSf.setText("512");
sf = 512;
txtAnoise.setText("0.1");
Anoise = 0.1;
txtHrmean.setText("60.0");
hrmean = 60.0;
txtHrstd.setText("1.0");
hrstd = 1.0;
txtSeed.setText("1");
seed = 1;
txtAmplitude.setText("1.4");
amplitude = 1.4;
/* Spectral Characteristics parameters */
txtFlo.setText("0.1");
flo = 0.1;
txtFhi.setText("0.25");
fhi = 0.25;
txtFlostd.setText("0.01");
flostd = 0.01;
txtFhistd.setText("0.01");
fhistd = 0.01;
txtLfhfratio.setText("0.5");
lfhfratio = 0.5;
/*
* ECG morphology: Order of extrema: [P Q R S T]
*/
theta[1]= -60.0;
theta[2]= -15.0;
theta[3]= 0.0;
theta[4]= 15.0;
theta[5]= 90.0;
a[1]= 1.2;
a[2]= -5.0;
a[3]= 30.0;
a[4]= -7.5;
a[5]= 0.75;
b[1]= 0.25;
b[2]= 0.1;
b[3]= 0.1;
b[4]= 0.1;
b[5]= 0.4;
//data tables
tiTable.getModel().setValueAt(new Double(theta[1]), 0, 0);
tiTable.getModel().setValueAt(new Double(theta[2]), 1, 0);
tiTable.getModel().setValueAt(new Double(theta[3]), 2, 0);
tiTable.getModel().setValueAt(new Double(theta[4]), 3, 0);
tiTable.getModel().setValueAt(new Double(theta[5]), 4, 0);
aiTable.getModel().setValueAt(new Double(a[1]), 0, 0);
aiTable.getModel().setValueAt(new Double(a[2]), 1, 0);
aiTable.getModel().setValueAt(new Double(a[3]), 2, 0);
aiTable.getModel().setValueAt(new Double(a[4]), 3, 0);
aiTable.getModel().setValueAt(new Double(a[5]), 4, 0);
biTable.getModel().setValueAt(new Double(b[1]), 0, 0);
biTable.getModel().setValueAt(new Double(b[2]), 1, 0);
biTable.getModel().setValueAt(new Double(b[3]), 2, 0);
biTable.getModel().setValueAt(new Double(b[4]), 3, 0);
biTable.getModel().setValueAt(new Double(b[5]), 4, 0);
/*
* ECG Animate parameters
*/
// convert into miliseconds interval
ecgAnimateInterval = (long)(1000/(sfecg));
}
private void resetECG(){
ecgGenerated = false;
clearParameters();
resetPlotArea();
resetButtons();
resetStatusBar();
}
/*
* Set the appropiate state of the controls for start the ECG Animation
*/
private void startECGAnimationSetControls(){
stopAnimateButton.setEnabled(true);
//exportButton.setEnabled(true);
clearButton.setEnabled(false);
generateButton.setEnabled(false);
paramButton.setEnabled(false);
zoomInButton.setEnabled(false);
zoomOutButton.setEnabled(false);
startAnimateButton.setEnabled(false);
}
/*
* Set the appropiate state of the controls for stop the ECG Animation
*/
private void stopECGAnimationSetControls(){
startAnimateButton.setEnabled(true);
clearButton.setEnabled(true);
generateButton.setEnabled(true);
paramButton.setEnabled(true);
zoomInButton.setEnabled(true);
zoomOutButton.setEnabled(true);
stopAnimateButton.setEnabled(false);
}
/*
* Enable the buttons after generating the ecg Data.
*/
private void enableButtons(){
startAnimateButton.setEnabled(true);
exportButton.setEnabled(true);
clearButton.setEnabled(true);
zoomInButton.setEnabled(true);
zoomOutButton.setEnabled(true);
}
private void resetButtons(){
stopAnimateButton.setEnabled(false);
startAnimateButton.setEnabled(false);
exportButton.setEnabled(false);
clearButton.setEnabled(false);
zoomInButton.setEnabled(false);
zoomOutButton.setEnabled(false);
}
private void resetPlotArea(){
lblMaxAmplitude.setText("1.4");
lblMinAmplitude.setText("-1.4");
readyToPlot = false;
plotScrollBarValue = 0;
}
private void resetStatusBar(){
txtStatus.setText(null);
txtStatus.append("**********************************************************\n");
txtStatus.append("Change desired ECG Parameters\n");
txtStatus.append("and then click 'Generate' button to generate and plot data\n");
txtStatus.append("**********************************************************");
}
private void clearButtonActionPerformed(java.awt.event.ActionEvent evt) {//GEN-FIRST:event_clearButtonActionPerformed
desktopPane.setCursor(java.awt.Cursor.getPredefinedCursor(java.awt.Cursor.WAIT_CURSOR));
paramDialog.hide();
// Delete the DataTable
clearDataTable();
resetECG();
ecgFrame.repaint();
desktopPane.setCursor(java.awt.Cursor.getPredefinedCursor(java.awt.Cursor.DEFAULT_CURSOR));
}//GEN-LAST:event_clearButtonActionPerformed
private void stopAnimateButtonActionPerformed(java.awt.event.ActionEvent evt) {//GEN-FIRST:event_stopAnimateButtonActionPerformed
paramDialog.hide();
/* Stop the Animate Plotting Task */
ecgAnimateTimer.cancel();
ecgAnimateFlg =false;
/* Enable automatic plot */
readyToPlot = true;
/* Repaint Plot Area */
ecgFrame.repaint();
/* Set the Animate Buttons */
stopECGAnimationSetControls();
}//GEN-LAST:event_stopAnimateButtonActionPerformed
private boolean checkParameters(){
txtStatus.append("Starting to check ECG parameters entered...\n");
boolean RetValue = true;
//ECG Sampling frequency flag
boolean sfecg_flg = true;
//Internal Sampling frequency flag
boolean sf_flg = true;
/* General Intergace parameters */
try {
N = Integer.valueOf(txtN.getText()).intValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'Approximate number of heart beats' entered, please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
sfecg = Integer.valueOf(txtSfecg.getText()).intValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'ECG Sampling Frequency' entered, please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
sfecg_flg = false;
RetValue = false;
}
if(sfecg_flg){
try {
sf = Integer.valueOf(txtSf.getText()).intValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'Internal Sampling Frequency' entered, please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
sf_flg = false;
RetValue = false;
}
}
// Check the Internal frequency respect to ECG frequency
if(sfecg_flg && sf_flg){
if(((int)Math.IEEEremainder(sf, sfecg)) != 0){
txtStatus.append("Internal sampling frequency must be an integer multiple of the\n");
txtStatus.append("ECG sampling frequency!, that currently is = " + sfecg + " Hertz\n");
RetValue = false;
}
}
try {
Anoise = Double.valueOf(txtAnoise.getText()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'Amplitude of additive uniform noise' entered, please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
hrmean = Double.valueOf(txtHrmean.getText()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'Heart rate mean' entered, please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
hrstd = Double.valueOf(txtHrstd.getText()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'Heart rate standard deviation' entered, please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
seed = Integer.valueOf(txtSeed.getText()).intValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'seed' entered, please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
amplitude = Double.valueOf(txtAmplitude.getText()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'Plot Area Amplitude' entered, please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
/* Spectral Characteristics parameters */
try {
flo = Double.valueOf(txtFlo.getText()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'Low frequency' entered, please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
fhi = Double.valueOf(txtFhi.getText()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'High frequency' entered, please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
flostd = Double.valueOf(txtFlostd.getText()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'Low frequency standard deviation' entered, please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
fhistd = Double.valueOf(txtFhistd.getText()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'High frequency standard deviation' entered, please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
lfhfratio = Double.valueOf(txtLfhfratio.getText()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'LF/HF ratio' entered, please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
/*
* ECG morphology: Order of extrema: [P Q R S T]
*/
// theta
try {
theta[1] = Double.valueOf(tiTable.getValueAt(0,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'theta' value entered (position 1), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
theta[2] = Double.valueOf(tiTable.getValueAt(1,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'theta' value entered (position 2), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
theta[3] = Double.valueOf(tiTable.getValueAt(2,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'theta' value entered (position 3), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
theta[4] = Double.valueOf(tiTable.getValueAt(3,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'theta' value entered (position 4), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
theta[5] = Double.valueOf(tiTable.getValueAt(4,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'theta' value entered (position 5), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
// a
try {
a[1] = Double.valueOf(aiTable.getValueAt(0,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'a' value entered (position 1), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
a[2] = Double.valueOf(aiTable.getValueAt(1,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'a' value entered (position 2), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
a[3] = Double.valueOf(aiTable.getValueAt(2,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'a' value entered (position 3), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
a[4] = Double.valueOf(aiTable.getValueAt(3,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'a' value entered (position 4), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
a[5] = Double.valueOf(aiTable.getValueAt(4,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'a' value entered (position 5), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
// b
try {
b[1] = Double.valueOf(biTable.getValueAt(0,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'b' value entered (position 1), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
b[2] = Double.valueOf(biTable.getValueAt(1,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'b' value entered (position 2), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
b[3] = Double.valueOf(biTable.getValueAt(2,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'b' value entered (position 3), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
b[4] = Double.valueOf(biTable.getValueAt(3,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'b' value entered (position 4), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
try {
b[5] = Double.valueOf(biTable.getValueAt(4,0).toString()).doubleValue();
} catch(java.lang.NumberFormatException e){
txtStatus.append("Incorrect 'b' value entered (position 5), please correct it!\n");
txtStatus.append("Exception Error : " + e + "\n");
RetValue = false;
}
/*
* ECG Animate parameters
*/
// convert into miliseconds interval
ecgAnimateInterval = (long)(1000/(sfecg));
if(RetValue){
txtStatus.append("All parameters are valid!.\n");
}else{
txtStatus.append("There were errors in some parameters!.\n");
}
txtStatus.append("Finished checking ECG parameters.\n\n");
return(RetValue);
}
/*************************
* THE ECG FUNCTION
**************************/
boolean ecgFunction(){
boolean RetValue;
txtStatus.append("Starting to generate ECG table data....\n");
ecgCalc Ecg = new ecgCalc();
RetValue = Ecg.dorun();
txtStatus.append("Finished generating ECG table data.\n\n");
return(RetValue);
}
private void generateButtonActionPerformed(java.awt.event.ActionEvent evt) {//GEN-FIRST:event_generateButtonActionPerformed
desktopPane.setCursor(java.awt.Cursor.getPredefinedCursor(java.awt.Cursor.WAIT_CURSOR));
paramDialog.hide();
/*
* Clear Status text.
*/
txtStatus.setText(null);
txtStatus.append("************************************************************\n");
txtStatus.append("ECGSYN:\nA program for generating a realistic synthetic ECG\n\n");
txtStatus.append("Copyright (c) 2003 by Patrick McSharry & Gari Clifford.\n");
txtStatus.append("All rights reserved.\n");
txtStatus.append("See IEEE Transactions On Biomedical Engineering, 50(3),\n289-294, March 2003.\n\n");
txtStatus.append("Contact:\nP. McSharry ([email protected])\nG. Clifford ([email protected])\n");
txtStatus.append("************************************************************\n\n");
txtStatus.append("ECG process started.\n\n");
txtStatus.append("Starting to clear table data and widgets values....\n");
/*
* Set the Amplitude labels
*/
lblMaxAmplitude.setText(txtAmplitude.getText());
lblMinAmplitude.setText("-" + txtAmplitude.getText());
/*
* Re init the plot state.
* Disable repaint for the moment, until we finish the FFT function.
*/
readyToPlot = false;
plotScrollBarValue = 0;
plotScrollBar.setMaximum(0);
/* Delete any data on the Data Table. */
clearDataTable();
txtStatus.append("Finished clearing table data and widgets values.\n\n");
/*
* Call the ECG funtion to calculate the data into the Data Table.
*/
if(ecgFunction()){
txtStatus.append("Starting to plot ECG table data....\n");
/*
* if the # Data Table rows is less than the ecgFrame width, we do not
* need the scrollbar
*/
int rows = tableValuesModel.getRowCount();
if(rows > ecgFrame.getBounds().width){
plotScrollBar.setMaximum(rows - ecgFrame.getBounds().width - 1);
}
/*
* Only plot if there's data in the table.
*/
if(rows > 0){
readyToPlot = true;
ecgGenerated = true;
enableButtons();
}else{
txtStatus.append("No data to plot!.\n");
}
ecgFrame.repaint();
txtStatus.append("Finished plotting ECG table data.\n\n");
}
txtStatus.append("Finsihed ECG process.\n");
txtStatus.append("************************************************************\n");
desktopPane.setCursor(java.awt.Cursor.getPredefinedCursor(java.awt.Cursor.DEFAULT_CURSOR));
}//GEN-LAST:event_generateButtonActionPerformed
// Variables declaration - do not modify//GEN-BEGIN:variables
private javax.swing.JScrollPane ExtremaLabelScrollPane;
private javax.swing.JTable ExtremaLabelTable;
private javax.swing.JScrollPane TableScrollPane;
private javax.swing.JScrollPane aiScrollPane;
private javax.swing.JTable aiTable;
private javax.swing.JDialog alert;
private javax.swing.JButton alertButton;
private javax.swing.JDesktopPane alertDesktopPane;
private javax.swing.JTextArea alertText;
private javax.swing.JLabel alertTitle;
private javax.swing.JDesktopPane animateDesktopPane;
private javax.swing.JScrollPane biScrollPane;
private javax.swing.JTable biTable;
private javax.swing.JDesktopPane calculateDesktopPane;
private javax.swing.JButton clearButton;
private javax.swing.JButton closeParamDialogButton;
private javax.swing.JDesktopPane desktopPane;
private javax.swing.JScrollPane ecgPlotArea;
private javax.swing.JInternalFrame ecgWindow;
private javax.swing.JButton exportButton;
private javax.swing.JDialog exportDialog;
private javax.swing.JPanel extremaPanel;
private javax.swing.JPanel generalInterfacePanel;
private javax.swing.JButton generateButton;
private javax.swing.JDialog helpDialog;
private javax.swing.JEditorPane helpEditorPane;
private javax.swing.JInternalFrame helpInternalFrame;
private javax.swing.JScrollPane helpScrollPane;
private javax.swing.JLabel jLabel1;
private javax.swing.JLabel jLabel2;
private javax.swing.JLabel jLabel3;
private javax.swing.JLabel jLabel4;
private javax.swing.JLabel jLabel5;
private javax.swing.JLabel jLabel6;
private javax.swing.JLabel jLabel7;
private javax.swing.JLabel lblAmplitude;
private javax.swing.JLabel lblAnoise;
private javax.swing.JLabel lblFhi;
private javax.swing.JLabel lblFhistd;
private javax.swing.JLabel lblFlo;
private javax.swing.JLabel lblFlostd;
private javax.swing.JLabel lblGeneralTitle;
private javax.swing.JLabel lblHrmean;
private javax.swing.JLabel lblHrstd;
private javax.swing.JLabel lblLfhfratio;
private javax.swing.JLabel lblMaxAmplitude;
private javax.swing.JLabel lblMinAmplitude;
private javax.swing.JLabel lblMorphologyTitle;
private javax.swing.JLabel lblN;
private javax.swing.JLabel lblOrigin;
private javax.swing.JLabel lblSeed;
private javax.swing.JLabel lblSf;
private javax.swing.JLabel lblSfecg;
private javax.swing.JLabel lblSpectralTitle;
private javax.swing.JLabel lblXAxis;
private javax.swing.JButton paramButton;
private javax.swing.JDesktopPane paramDesktopPane;
private javax.swing.JDialog paramDialog;
private javax.swing.JButton paramHelpButton;
private javax.swing.JTabbedPane paramTabbedPane;
private javax.swing.JScrollBar plotScrollBar;
private javax.swing.JButton resetParamDialogButton;
private javax.swing.JButton saveParamDialogButton;
private javax.swing.JPanel spectralCharacteristicsPanel;
private javax.swing.JButton startAnimateButton;
private javax.swing.JScrollPane statusScrollPane;
private javax.swing.JButton stopAnimateButton;
private javax.swing.JTable tableValues;
private javax.swing.JScrollPane tiScrollPane;
private javax.swing.JTable tiTable;
private javax.swing.JTextField txtAmplitude;
private javax.swing.JTextField txtAnoise;
private javax.swing.JTextField txtFhi;
private javax.swing.JTextField txtFhistd;
private javax.swing.JTextField txtFlo;
private javax.swing.JTextField txtFlostd;
private javax.swing.JTextField txtHrmean;
private javax.swing.JTextField txtHrstd;
private javax.swing.JTextField txtLfhfratio;
private javax.swing.JTextField txtN;
private javax.swing.JTextField txtSeed;
private javax.swing.JTextField txtSf;
private javax.swing.JTextField txtSfecg;
private javax.swing.JTextArea txtStatus;
private javax.swing.JDesktopPane zommDesktopPane;
private javax.swing.JButton zoomInButton;
private javax.swing.JButton zoomOutButton;
// End of variables declaration//GEN-END:variables
private javax.swing.table.DefaultTableModel tableValuesModel;
private ecgPanel ecgFrame;
/*
* This class is the AdjustmentListener for the
* scroll bar. So the events come here when the
* scroll bar is moved.
*/
public void adjustmentValueChanged(AdjustmentEvent evt){
plotScrollBarValue = plotScrollBar.getValue();
ecgFrame.repaint();
}
class ecgPanel extends javax.swing.JPanel{
public void paintComponent(Graphics g){
// First call the paintComponent of the
// superclass, in this case JPanel.
super.paintComponent(g);
/* Draw the plot frame. */
g.setColor(frameLineColor);
g.drawLine(0, posFrameY, ecgFrame.getBounds().width, posFrameY);
g.drawLine(0, posOriginY, this.getBounds().width, posOriginY);
g.drawLine(0, horzScaleY, this.getBounds().width, horzScaleY);
if(readyToPlot){
int rows = tableValuesModel.getRowCount();
int x, y, i;
int plotLimit;
int initialZero;
int curSecond, lastSecond;
String strValue;
/*
* Set the first point to the current Table row
*/
initialZero = (int)(Double.valueOf(tableValues.getValueAt(plotScrollBarValue, 0).toString()).doubleValue() / plotZoom);
lastSecond = (int)(Double.valueOf(tableValues.getValueAt(plotScrollBarValue, 0).toString()).doubleValue());
x = 0;
y = posOriginY - (int)(Double.valueOf(tableValues.getValueAt(plotScrollBarValue, 1).toString()).doubleValue() * frameAmplitude / amplitude);
Point lastPoint = new java.awt.Point(x, y);
i= plotScrollBarValue;
while((x <= this.getBounds().width)&& (i <=rows)){
curSecond = (int)(Double.valueOf(tableValues.getValueAt(i, 0).toString()).doubleValue());
if(curSecond > lastSecond){
lastSecond = curSecond;
// Convert the x value to a string
strValue = FormatNumber.toString(Double.valueOf(tableValues.getValueAt(i, 0).toString()).doubleValue(), upLimit, loLimit, 2);
/*
* Plot the X axes number values (the Time).
*/
g.setColor(axesNumColor);
drawText(g, strValue,
x, horzScaleY, horzScaleWidth, horzScaleHeight,
fScaleNumSize,LEFT);
g.setColor(frameInsideLineColor);
g.drawLine(x, posFrameY, x, horzScaleY + 5);
}
/*
* Plot a line between the las point and the current point.
* This to create a illusion to connect the two points.
*/
g.setColor(ecgPlotColor);
g.drawLine(lastPoint.x, lastPoint.y, x, y);
/*
* Set the current point to be the last, and
* get a new point to plot in the following loop.
*/
lastPoint.setLocation(x, y);
i+= 1;
x = (int)(Double.valueOf(tableValues.getValueAt(i, 0).toString()).doubleValue() / plotZoom) - initialZero;
y = posOriginY - (int)(Double.valueOf(tableValues.getValueAt(i, 1).toString()).doubleValue() * frameAmplitude / amplitude);
}
}
}
}
class ecgCalc{
/* C defines */
private final double PI = 2.0*Math.asin(1.0);
private final int NR_END = 1;
private final int IA = 16807;
private final long IM = 2147483647;
private final double AM = (1.0/IM);
private final long IQ = 127773;
private final int IR = 2836;
private final int NTAB = 32;
private final double NDIV = (1+(IM-1)/NTAB);
private final double EPS = 1.2e-7;
private final double RNMX = (1.0-EPS);
/*****************************************************************************
* DEFINE PARAMETERS AS GLOBAL VARIABLES *
*****************************************************************************/
private String outfile ="ecgsyn.dat";
// Order of extrema: [P Q R S T]
private double[] ti = new double[6]; /* ti converted in radians */
private double[] ai = new double[6]; /* new calculated a */
private double[] bi = new double[6]; /* new calculated b */
private int Necg = 0; /* Number of ECG outputs */
private int mstate = 3; /* System state space dimension */
private double xinitial = 1.0; /* Initial x co-ordinate value */
private double yinitial = 0.0; /* Initial y co-ordinate value */
private double zinitial = 0.04; /* Initial z co-ordinate value */
private long rseed;
private double h;
private double[] rr, rrpc;
/*
* Variables for static function rand()
*/
private long iy;
private long[] iv;
public ecgCalc(){
/* variables for static function ranq() */
iy=0;
iv = new long[NTAB];
}
/*--------------------------------------------------------------------------*/
/* UNIFORM DEVIATES */
/*--------------------------------------------------------------------------*/
private double rand(){
int j;
long k;
double temp;
boolean flg;
if(iy == 0)
flg = false;
else
flg = true;
if((rseed <= 0) || !flg){
if (-(rseed) < 1)
rseed = 1;
else
rseed = -rseed;
for (j=NTAB+7; j>=0; j--) {
k=(rseed)/IQ;
rseed=IA*(rseed-k*IQ)-IR*k;
if (rseed < 0)
rseed += IM;
if (j < NTAB)
iv[j] = rseed;
}
iy=iv[0];
}
k=(rseed)/IQ;
rseed=IA*(rseed-k*IQ)-IR*k;
if (rseed< 0)
rseed += IM;
j = (int)(iy/NDIV);
iy=iv[j];
iv[j] = rseed;
if ((temp=AM*iy) > RNMX)
return RNMX;
else
return temp;
}
/*
* FFT
*/
private void ifft(double[] data, long nn, int isign){
long n, mmax, m, istep, i, j;
double wtemp,wr,wpr,wpi,wi,theta;
double tempr,tempi;
double swap;
n=nn << 1;
j=1;
for (i=1; i< n; i+=2) {
if (j > i) {
//SWAP(data[j],data[i]);
swap = data[(int) j];
data[(int)j] = data[(int)i];
data[(int)i] = swap;
//SWAP(data[j+1],data[i+1]);
swap = data[(int)j+1];
data[(int)j+1] = data[(int)i+1];
data[(int)i+1] = swap;
}
m=n >> 1;
while (m >= 2 && j > m) {
j -= m;
m >>= 1;
}
j += m;
}
mmax=2;
while (n > mmax) {
istep=mmax << 1;
theta=isign*(6.28318530717959/mmax);
wtemp=Math.sin(0.5*theta);
wpr = -2.0*wtemp*wtemp;
wpi=Math.sin(theta);
wr=1.0;
wi=0.0;
for (m=1; m<mmax; m+=2) {
for (i=m; i<=n; i+=istep) {
j= i + mmax;
tempr=wr * data[(int)j] - wi * data[(int)j+1];
tempi=wr * data[(int)j+1] + wi * data[(int)j];
data[(int)j]= data[(int)i] - tempr;
data[(int)j+1]= data[(int)i+1] - tempi;
data[(int)i] += tempr;
data[(int)i+1] += tempi;
}
wr=(wtemp=wr)*wpr-wi*wpi+wr;
wi=wi*wpr+wtemp*wpi+wi;
}
mmax=istep;
}
}
/*
* STANDARD DEVIATION CALCULATOR
*/
/* n-by-1 vector, calculate standard deviation */
private double stdev(double[] x, int n){
int j;
double add,mean,diff,total;
add = 0.0;
for(j=1;j<=n;j++)
add += x[j];
mean = add/n;
total = 0.0;
for(j=1;j<=n;j++){
diff = x[j] - mean;
total += diff*diff;
}
return (Math.sqrt(total/((double)n-1)));
}
/*
* THE ANGULAR FREQUENCY
*/
private double angfreq(double t){
int i = 1 + (int)Math.floor(t/h);
return(2.0*PI/rrpc[i]);
}
/*--------------------------------------------------------------------------*/
/* THE EXACT NONLINEAR DERIVATIVES */
/*--------------------------------------------------------------------------*/
private void derivspqrst(double t0,double[] x, double[] dxdt){
int i,k;
double a0,w0,r0,x0,y0,z0;
double t,dt,dt2,zbase;
double[] xi, yi;
k = 5;
xi = new double[k + 1];
yi = new double[k + 1];
w0 = angfreq(t0);
r0 = 1.0; x0 = 0.0; y0 = 0.0; z0 = 0.0;
a0 = 1.0 - Math.sqrt((x[1]-x0)*(x[1]-x0) + (x[2]-y0)*(x[2]-y0))/r0;
for(i=1; i<=k; i++)
xi[i] = Math.cos(ti[i]);
for(i=1; i<=k; i++)
yi[i] = Math.sin(ti[i]);
zbase = 0.005* Math.sin(2.0*PI*fhi*t0);
t = Math.atan2(x[2],x[1]);
dxdt[1] = a0*(x[1] - x0) - w0*(x[2] - y0);
dxdt[2] = a0*(x[2] - y0) + w0*(x[1] - x0);
dxdt[3] = 0.0;
for(i=1; i<=k; i++){
dt = Math.IEEEremainder(t-ti[i], 2.0*PI);
dt2 = dt*dt;
dxdt[3] += -ai[i] * dt * Math.exp(-0.5*dt2/(bi[i]*bi[i]));
}
dxdt[3] += -1.0*(x[3] - zbase);
}
/*
* RUNGA-KUTTA FOURTH ORDER INTEGRATION
*/
private void Rk4(double[] y, int n, double x, double h, double[] yout){
int i;
double xh,hh,h6;
double[] dydx, dym, dyt, yt;
dydx= new double[n + 1];
dym = new double[n + 1];
dyt = new double[n + 1];
yt = new double[n + 1];
hh= h * 0.5;
h6= h/6.0;
xh= x + hh;
derivspqrst(x,y,dydx);
for (i=1; i<=n; i++)
yt[i]=y[i]+hh*dydx[i];
derivspqrst(xh,yt,dyt);
for (i=1; i<=n; i++)
yt[i]=y[i] + hh * dyt[i];
derivspqrst(xh,yt,dym);
for (i=1; i<=n; i++){
yt[i]=y[i] + h * dym[i];
dym[i] += dyt[i];
}
derivspqrst(x+h,yt,dyt);
for (i=1; i<=n; i++)
yout[i]=y[i] + h6 * (dydx[i]+dyt[i]+2.0*dym[i]);
}
/*
* GENERATE RR PROCESS
*/
private void rrprocess(double[] rr, double flo, double fhi,
double flostd, double fhistd, double lfhfratio,
double hrmean, double hrstd, double sf, int n)
{
int i,j;
double c1,c2,w1,w2,sig1,sig2,rrmean,rrstd,xstd,ratio;
double df;//,dw1,dw2;
double[] w, Hw, Sw, ph0, ph, SwC;
w = new double[n+1];
Hw = new double[n+1];
Sw = new double[n+1];
ph0= new double[(int)(n/2-1 +1)];
ph = new double[n+1];
SwC= new double[(2*n)+1];
w1 = 2.0*PI*flo;
w2 = 2.0*PI*fhi;
c1 = 2.0*PI*flostd;
c2 = 2.0*PI*fhistd;
sig2 = 1.0;
sig1 = lfhfratio;
rrmean = 60.0/hrmean;
rrstd = 60.0*hrstd/(hrmean*hrmean);
df = sf/(double)n;
for(i=1; i<=n; i++)
w[i] = (i-1)*2.0*PI*df;
for(i=1; i<=n; i++){
//dw1 = w[i]-w1;
//dw2 = w[i]-w2;
Hw[i] = (sig1*Math.exp(-0.5*(Math.pow(w[i]-w1,2)/Math.pow(c1,2))) / Math.sqrt(2*PI*c1*c1))
+ (sig2*Math.exp(-0.5*(Math.pow(w[i]-w2,2)/Math.pow(c2,2))) / Math.sqrt(2*PI*c2*c2));
}
for(i=1; i<=n/2; i++)
Sw[i] = (sf/2.0)* Math.sqrt(Hw[i]);
for(i=n/2+1; i<=n; i++)
Sw[i] = (sf/2.0)* Math.sqrt(Hw[n-i+1]);
/* randomise the phases */
for(i=1; i<=n/2-1; i++)
ph0[i] = 2.0*PI*rand();
ph[1] = 0.0;
for(i=1; i<=n/2-1; i++)
ph[i+1] = ph0[i];
ph[n/2+1] = 0.0;
for(i=1; i<=n/2-1; i++)
ph[n-i+1] = - ph0[i];
/* make complex spectrum */
for(i=1; i<=n; i++)
SwC[2*i-1] = Sw[i]* Math.cos(ph[i]);
for(i=1; i<=n; i++)
SwC[2*i] = Sw[i]* Math.sin(ph[i]);
/* calculate inverse fft */
ifft(SwC,n,-1);
/* extract real part */
for(i=1; i<=n; i++)
rr[i] = (1.0/(double)n)*SwC[2*i-1];
xstd = stdev(rr,n);
ratio = rrstd/xstd;
for(i=1; i<=n; i++)
rr[i] *= ratio;
for(i=1; i<=n; i++)
rr[i] += rrmean;
}
/*
* DETECT PEAKS
*/
private void detectpeaks(double[] ipeak, double[] x, double[] y, double[] z, int n){
int i, j, j1, j2, jmin, jmax, d;
double thetap1, thetap2, thetap3, thetap4, thetap5;
double theta1, theta2, d1, d2, zmin, zmax;
thetap1 = ti[1];
thetap2 = ti[2];
thetap3 = ti[3];
thetap4 = ti[4];
thetap5 = ti[5];
for(i=1; i<=n; i++)
ipeak[i] = 0.0;
theta1 = Math.atan2(y[1],x[1]);
for(i=1; i<n; i++){
theta2 = Math.atan2(y[i+1], x[i+1]);
if( (theta1 <= thetap1) && (thetap1 <= theta2) ){
d1 = thetap1 - theta1;
d2 = theta2 - thetap1;
if(d1 < d2)
ipeak[i] = 1.0;
else
ipeak[i+1] = 1.0;
}else if( (theta1 <= thetap2) && (thetap2 <= theta2) ){
d1 = thetap2 - theta1;
d2 = theta2 - thetap2;
if(d1 < d2)
ipeak[i] = 2.0;
else
ipeak[i+1] = 2.0;
}else if( (theta1 <= thetap3) && (thetap3 <= theta2) ){
d1 = thetap3 - theta1;
d2 = theta2 - thetap3;
if(d1 < d2)
ipeak[i] = 3.0;
else
ipeak[i+1] = 3.0;
}else if( (theta1 <= thetap4) && (thetap4 <= theta2) ){
d1 = thetap4 - theta1;
d2 = theta2 - thetap4;
if(d1 < d2)
ipeak[i] = 4.0;
else
ipeak[i+1] = 4.0;
}else if( (theta1 <= thetap5) && (thetap5 <= theta2) ){
d1 = thetap5 - theta1;
d2 = theta2 - thetap5;
if(d1 < d2)
ipeak[i] = 5.0;
else
ipeak[i+1] = 5.0;
}
theta1 = theta2;
}
/* correct the peaks */
d = (int)Math.ceil(sfecg/64);
for(i=1; i<=n; i++){
if( ipeak[i]==1 || ipeak[i]==3 || ipeak[i]==5 ){
j1 = (1 > (i-d) ? 1 : (i-d)); //MAX(1,i-d);
j2 = (n < (i+d) ? n : (i+d)); //MIN(n,i+d);
jmax = j1;
zmax = z[j1];
for(j=j1+1;j<=j2;j++){
if(z[j] > zmax){
jmax = j;
zmax = z[j];
}
}
if(jmax != i){
ipeak[jmax] = ipeak[i];
ipeak[i] = 0;
}
} else if( ipeak[i]==2 || ipeak[i]==4 ){
j1 = (1 > (i-d) ? 1 : (i-d));//MAX(1,i-d);
j2 = (n < (i+d) ? n : (i+d)); //MIN(n,i+d);
jmin = j1;
zmin = z[j1];
for(j=j1+1;j<=j2;j++){
if(z[j] < zmin){
jmin = j;
zmin = z[j];
}
}
if(jmin != i){
ipeak[jmin] = ipeak[i];
ipeak[i] = 0;
}
}
}
}
/*
* DORUN PART OF PROGRAM
*/
public boolean dorun(){
boolean RetValue = true;
int i, j, k, Nrr, Nt, Nts;
int q;
double[] x;
double tstep, tecg, rrmean, hrfact, hrfact2;
double qd;
double[] xt, yt, zt, xts, yts, zts;
double timev, zmin, zmax, zrange;
double[] ipeak;
// perform some checks on input values
q = (int) Math.rint(sf/sfecg);
qd = (double)sf/(double)sfecg;
/* convert angles from degrees to radians and copy a vector to ai*/
for(i=1; i <= 5; i++){
ti[i] = theta[i] * PI/180.0;
ai[i] = a[i];
}
/* adjust extrema parameters for mean heart rate */
hrfact = Math.sqrt(hrmean/60);
hrfact2 = Math.sqrt(hrfact);
for(i=1; i <= 5; i++)
bi[i] = b[i] * hrfact;
ti[1] *= hrfact2;
ti[2] *= hrfact;
ti[3] *= 1.0;
ti[4] *= hrfact;
ti[5] *= 1.0;
/* declare state vector */
//x=dvector(1,mstate);
x= new double[4];
txtStatus.append("Approximate number of heart beats: " + N +"\n");
txtStatus.append("ECG sampling frequency: " + sfecg + " Hertz\n");
txtStatus.append("Internal sampling frequency: " + sf + " Hertz\n");
txtStatus.append("Amplitude of additive uniformly distributed noise: " + Anoise + " mV\n");
txtStatus.append("Heart rate mean: " + hrmean + " beats per minute\n");
txtStatus.append("Heart rate std: " + hrstd + " beats per minute\n");
txtStatus.append("Low frequency: " + flo + " Hertz\n");
txtStatus.append("High frequency std: " + fhistd + " Hertz\n");
txtStatus.append("Low frequency std: " + flostd + " Hertz\n");
txtStatus.append("High frequency: " + fhi + " Hertz\n");
txtStatus.append("LF/HF ratio: " + lfhfratio + "\n");
txtStatus.append("time step milliseconds: " + ecgAnimateInterval + "\n\n");
txtStatus.append("Order of Extrema:\n");
txtStatus.append(" theta(radians)\n");
txtStatus.append("P: ["+ ti[1] + "\t]\n");
txtStatus.append("Q: ["+ ti[2] + "\t]\n");
txtStatus.append("R: ["+ ti[3] + "\t]\n");
txtStatus.append("S: ["+ ti[4] + "\t]\n");
txtStatus.append("T: ["+ ti[5] + "\t]\n\n");
txtStatus.append(" a(calculated)\n");
txtStatus.append("P: ["+ ai[1] + "\t]\n");
txtStatus.append("Q: ["+ ai[2] + "\t]\n");
txtStatus.append("R: ["+ ai[3] + "\t]\n");
txtStatus.append("S: ["+ ai[4] + "\t]\n");
txtStatus.append("T: ["+ ai[5] + "\t]\n\n");
txtStatus.append(" b(calculated)\n");
txtStatus.append("P: ["+ bi[1] + "\t]\n");
txtStatus.append("Q: ["+ bi[2] + "\t]\n");
txtStatus.append("R: ["+ bi[3] + "\t]\n");
txtStatus.append("S: ["+ bi[4] + "\t]\n");
txtStatus.append("T: ["+ bi[5] + "\t]\n\n");
/* Initialise the vector */
x[1] = xinitial;
x[2] = yinitial;
x[3] = zinitial;
/* initialise seed */
rseed = -seed;
/* calculate time scales */
h = 1.0/(double)sf;
tstep = 1.0/(double)sfecg;
/* calculate length of RR time series */
rrmean = (60.0/hrmean);
Nrr=(int)Math.pow(2.0, Math.ceil(Math.log(N*rrmean*sf)/Math.log(2.0)));
txtStatus.append("Using " + Nrr + " = 2^ "+ (int)(Math.log(1.0*Nrr)/Math.log(2.0)) + " samples for calculating RR intervals\n");
/* create rrprocess with required spectrum */
rr = new double[Nrr + 1];
rrprocess(rr, flo, fhi, flostd, fhistd, lfhfratio, hrmean, hrstd, sf, Nrr);
/* create piecewise constant rr */
rrpc = new double[(2*Nrr) + 1];
tecg = 0.0;
i = 1;
j = 1;
while(i <= Nrr){
tecg += rr[j];
j = (int) Math.rint(tecg/h);
for(k=i; k<=j; k++)
rrpc[k] = rr[i];
i = j+1;
}
Nt = j;
/* integrate dynamical system using fourth order Runge-Kutta*/
xt = new double[Nt + 1];
yt = new double[Nt + 1];
zt = new double[Nt + 1];
timev = 0.0;
for(i=1; i<=Nt; i++){
xt[i] = x[1];
yt[i] = x[2];
zt[i] = x[3];
Rk4(x, mstate, timev, h, x);
timev += h;
}
/* downsample to ECG sampling frequency */
xts = new double[Nt + 1];
yts = new double[Nt + 1];
zts = new double[Nt + 1];
j=0;
for(i=1; i<=Nt; i+=q){
j++;
xts[j] = xt[i];
yts[j] = yt[i];
zts[j] = zt[i];
}
Nts = j;
/* do peak detection using angle */
ipeak = new double[Nts + 1];
detectpeaks(ipeak, xts, yts, zts, Nts);
/* scale signal to lie between -0.4 and 1.2 mV */
zmin = zts[1];
zmax = zts[1];
for(i=2; i<=Nts; i++){
if(zts[i] < zmin)
zmin = zts[i];
else if(zts[i] > zmax)
zmax = zts[i];
}
zrange = zmax-zmin;
for(i=1; i<=Nts; i++)
zts[i] = (zts[i]-zmin)*(1.6)/zrange - 0.4;
/* include additive uniformly distributed measurement noise */
for(i=1; i<=Nts; i++)
zts[i] += Anoise*(2.0*rand() - 1.0);
/*
* insert into the ECG data table
*/
txtStatus.append("Inserting rows...\n");
for(i=1;i<=Nts;i++){
//fprintf(fp,"%f %f %d\n",(i-1)*tstep,zts[i],(int)ipeak[i]);
Vector nuevoRow = new Vector(3);
nuevoRow.addElement(new String(Double.toString((i-1)*tstep)));
nuevoRow.addElement(new String(Double.toString(zts[i])));
nuevoRow.addElement(new String(Integer.toString((int)ipeak[i])));
tableValuesModel.addRow(nuevoRow);
}
txtStatus.append("Finished inserting (" + i + ") rows.\n");
//RetValue = false;
return(RetValue);
}
}
/*
* Class to plot the ECG animation
*/
class ECGAnimate extends TimerTask{
int x = 0;
int y = posOriginY - (int)(Double.valueOf(tableValues.getValueAt(ecgAnimateCurRow, 1).toString()).doubleValue() * frameAmplitude / amplitude);
int curSecond = 0;
int lastSecond = 0;
Graphics ga = ecgFrame.getGraphics();
public void run(){
curSecond = (int)(Double.valueOf(tableValues.getValueAt(ecgAnimateCurRow, 0).toString()).doubleValue());
if(curSecond > lastSecond){
lastSecond = curSecond;
/*
* Plot the X axes number values (the Time).
*/
ga.setColor(axesNumColor);
drawText(ga, FormatNumber.toString(Double.valueOf(tableValues.getValueAt(ecgAnimateCurRow, 0).toString()).doubleValue(), upLimit, loLimit, 2),
x, horzScaleY, horzScaleWidth, horzScaleHeight,
fScaleNumSize,LEFT);
ga.setColor(frameInsideLineColor);
ga.drawLine(x, posFrameY, x, horzScaleY + 5);
}
ga.setColor(ecgPlotColor);
ga.drawLine(ecgAnimateLastPoint.x, ecgAnimateLastPoint.y, x, y);
ecgAnimateCurRow += 1;
if(ecgAnimateCurRow >= ecgAnimateNumRows){
/*
* If we reach the end of the Data Table, loop again entire table.
*/
ecgFrame.repaint();
ecgAnimateCurRow = 0;
ecgAnimateInitialZero = 0;
x = 0;
y = posOriginY - (int)(Double.valueOf(tableValues.getValueAt(ecgAnimateCurRow, 1).toString()).doubleValue() * frameAmplitude / amplitude);
ecgAnimateLastPoint.setLocation(x, y);
curSecond = 0;
lastSecond = 0;
} else if(x > ecgAnimatePanelWidth){
/*
* If we not reached the end of the Data Table, but we reach to the limit of
* the Plot Area. so reset the X coordinate to begin again.
*/
ecgFrame.repaint();
x = 0;
y = posOriginY - (int)(Double.valueOf(tableValues.getValueAt(ecgAnimateCurRow, 1).toString()).doubleValue() * frameAmplitude / amplitude);
ecgAnimateInitialZero = (int)(Double.valueOf(tableValues.getValueAt(ecgAnimateCurRow, 0).toString()).doubleValue() / plotZoom);
ecgAnimateLastPoint.setLocation(x, y);
//curSecond = 0;
//lastSecond = 0;
} else{
ecgAnimateLastPoint.setLocation(x, y);
x = (int)(Double.valueOf(tableValues.getValueAt(ecgAnimateCurRow, 0).toString()).doubleValue() / plotZoom) - ecgAnimateInitialZero;
y = posOriginY - (int)(Double.valueOf(tableValues.getValueAt(ecgAnimateCurRow, 1).toString()).doubleValue() * frameAmplitude / amplitude);
}
}
}
/*
* class for verifying that the value of JtextField is a double number
*/
class doubleVerifier extends InputVerifier{
public boolean verify(JComponent input) {
JTextField textF = (JTextField) input;
double dNumber;
boolean RetValue = true;
try {
dNumber = Double.valueOf(textF.getText()).doubleValue();
} catch(java.lang.NumberFormatException e){
getToolkit().beep();
alert.setTitle("Error!!!");
alertText.setText("You have to enter a double number, please retry!!!");
alert.show();
RetValue = false;
}
return(RetValue);
}
}
/*
* class for verifying that the value of JtextField is an integer number
*/
class integerVerifier extends InputVerifier{
public boolean verify(JComponent input) {
JTextField textF = (JTextField) input;
int dNumber;
boolean RetValue = true;
try {
dNumber = Integer.valueOf(textF.getText()).intValue();
} catch(java.lang.NumberFormatException e){
getToolkit().beep();
alert.setTitle("Error!!!");
alertText.setText("You have to enter an integer number, please retry!!!");
alert.show();
RetValue = false;
}
return(RetValue);
}
}
/*
* class for verifying the value of the ECG Sampling frequency
*/
class sfecgVerifier extends InputVerifier{
public boolean verify(JComponent input) {
JTextField textF = (JTextField) input;
int dNumber;
boolean RetValue = true;
try {
dNumber = Integer.valueOf(textF.getText()).intValue();
txtSf.setText(Integer.toString(dNumber));
} catch(java.lang.NumberFormatException e){
getToolkit().beep();
alert.setTitle("Error!!!");
alertText.setText("You have to enter an integer number, please retry!!!");
alert.show();
RetValue = false;
}
return(RetValue);
}
}
/*
* class for verifying the value of the Internal Sampling frequency
*/
class sfVerifier extends InputVerifier{
public boolean verify(JComponent input) {
JTextField textF = (JTextField) input;
int dNumber;
boolean RetValue = true;
try {
dNumber = Integer.valueOf(textF.getText()).intValue();
int sfecgTemp;
sfecgTemp = Integer.valueOf(txtSfecg.getText()).intValue();
if(((int)Math.IEEEremainder(dNumber, sfecgTemp)) != 0){
getToolkit().beep();
alert.setTitle("Error!!!");
alertText.setText("Internal sampling frequency must be an integer multiple of the ECG sampling frequency, please retry!");
alert.show();
RetValue = false;
}
} catch(java.lang.NumberFormatException e){
getToolkit().beep();
alert.setTitle("Error!!!");
alertText.setText("You have to enter an integer number, please retry!!!");
alert.show();
RetValue = false;
}
return(RetValue);
}
}
}
